Electric Outboard Motor - EP14
EP-14 Electric Outboard - Image 2
Electric Outboard Motor - EP14
Electric Outboard Motor - EP14

EP-14 Electric Outboard

$4,950.00

-

Comparable HP:14HP
Voltage:48 Volts
Suggested Battery Package Options:
AGM – Victron – 12V / 130Ah (4 pack)
Solid State – 48V / 120Ah (6.0kWh) (1 pack)

Elco’s EP-14 utilizes a larger chassis than the EP-9.9. This turns into a bigger propeller that maximizes efficiency and provides extra torque when pontoon boats and larger sailboats need to overcome wind or waves while docking. 48-volt operation optimizes performance and efficiency.

Configure your electric outboard propulsion system using the steps below.

If your transom is 15″ or longer, a long shaft is recommended.

Step 2. Select Throttle Control, if remote throttle was chosen above.

(Remote throttle selection is not needed if tiller was chosen above)

Step 3. Select Batteries & Charger

If you do not have batteries and a charger, you will need to select either AGM or Lithium batteries with the matching charger type. If you already have batteries but need a charger, select the applicable charger based on the type of battery you have.

Step 4. Select Battery Connection Kit

Pre-assembled battery connection cables simplify motor installation. Our 7-foot electric battery cables and 18-inch battery jumper cables are adequately sized based on the motor amp draw. Swaged terminal ends are sealed with epoxy-impregnated heat-shrink tubing where they connect to marine-grade fuse blocks, Anderson motor connectors, and batteries.

Step 5. Select Battery Monitor

Battery monitors help you take better care of your battery. Your battery monitor also provides real-time and historical information on voltage, power consumption, and more.

  • *

    VICTRON BMV-700 BATTERY MONITOR KIT

    The BMV-700 is Victron’s newest high precision battery monitor. The essential function of a battery monitor is to calculate ampere-hours consumed and the state of charge of a battery. Ampere-hours consumed are calculated by integrating the current flowing in or out of the battery.

    AddRemove

    VICTRON BMV-712 BLUETOOTH BATTERY MONITOR KIT

    $243.00

    Built-in Bluetooth Communication - Monitor your batteries on Apple or Android smartphones, tablets, macbooks, and other devices Easy to Install.

    AddRemove

    Elco DASH App – Bluetooth Connector

    $345.00

    Elco’s DASH motor app wirelessly turns any iOS or Android mobile device into a full-function dashboard.

    (DASH Bluetooth connector required on the motor, included with purchase)

    Click Store to Download after install

    AddRemove

    Elco NMEA 2000 Gateway

    $545.00

    Elco NMEA 2000 Gateway: If you purchase the Elco NMEA 2000 gateway separately, it will be pre-installed in your Elco outboard or inboard. To ensure everything works smoothly, make sure your depth finder or chart plotter supports NMEA 2000, as features can vary by model. You’ll also need to buy a complete NMEA 2000 starter kit for installation. For the best results, consider consulting a marine professional for setup help.

    AddRemove

Step 6. Select Electric Trim and Tilt

Electric trim and tilt units simplify boat operation, increase performance and safety. This electric trim and tilt model matches this electric outboard.

Product total

Options total

Grand total

SKU: EP-14 Category: Tag:
Elco’s EP-14 utilizes a larger chassis than the EP-9.9. This turns a bigger propeller that maximizes efficiency and provides extra torque when pontoon boats and larger sailboats need to overcome wind or waves while docking. 48-volt operation optimizes performance and efficiency. Remote or tiller control and long or short shaft lengths accommodate most boats. NMEA 2000 and Elco’s DASH app seamlessly connect to navigation displays as well as wireless and wearable screens.

Not Ready To Buy?

Learn More

Specifications



BATTERY VOLTAGE (NOMINAL)48 Volts
BATTERY VOLTAGE (OPERATING RANGE)40-59 Volts
BATTERY CURRENT (MAXIMUM CONTINUOUS)130Ah
SUGGESTED BATTERY CAPACITY130Ah-225Ah
KILOWATTS (CONTINUOUS)6.2kW
STATIC THRUST275lbs
MAXIMUM RPM5000 RPM
PROPELLER3 - 9.25” x 8”
LOWER UNIT GEAR RATIO2.08:1
SUGGESTED FOR BOAT LENGTHS (LOA)10’-12’
SUGGESTED FOR BOAT WEIGHTS700lbs
COMPARABLE HORSEPOWER14HP
HP REPLACEMENT RANGE12-16HP
OUTBOARD WEIGHT85lbs
SHORT SHAFT OVERALL (LENGTH, WIDTH, HEIGHT)18.5"x11"x43"
SHORT SHAFT OVERALL (LENGTH, WIDTH, HEIGHT)18.5"x11"x46"
MSRP$4,950
